PLF-1200N Full-Auto Photoelectric Paper Trimming Machine for Filter Production Equipment

Name: PLF1200N FullAuto Photoelectric Paper Trimming Machine for Filter Production Equipment
Brand: leiman
Price: 8500 USD

Wholesale PLF-1200N Full-Auto Photoelectric Paper Trimming Machine for Filter Production Equipment from china suppliers

Brand Name : leiman

Model Number : PLF-1200N

Certification : IS9001

Place of Origin : China

MOQ : 1set

Price : USD 8500 /SET

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 5/SET/Per month

Packaging Details : wooden case packing

Width : 1300C type

Cutting thickness : 20g-300g

max diameter of raw material rewinding : 800mm

Max width of slitting material : 1300mm

Winding inflatable shaft : 74mm

Deviation Correction Accuracy : ±0.5 mm

Number of shafts at the same time : 2

Slitting Accuracy : 10 to 200 m/min

Total Power : 5 W

Contact Now

The Best Quality PLF-1200N Full-Auto Photoelectric Paper Trimming Machine for Filter Production Equipment

Machine parameters

Specification

Product Name	PLF-1200N
Width	1300C type
Cutting Thickness	20–300 g/m² (depending on different raw materials)
Max. Diameter of Raw Material Unwindin	φ800 mm
Max. Diameter of Raw Material Rewinding	φ800 mm
Max. Width of Slitting Material	1300 mm
Winding Inflatable Shaft	φ74 mm

Number of Rewinding Shafts at the Same Time	2 (double shaft rewinding)
Deviation Correction Accuracy	±0.5 mm
Slitting Accuracy	±0.5 mm
Speed	10–200 m/min
Total Power	5 W
Body Color	gray cover white (other colors are optional)
Use automatic photoelectric correction	according to different raw materials and customer specific requirements

Features

This machine uses a DC motor to keep it running smoothly during acceleration; (frequency conversion speed regulation can also be used)
Automatic meter counting, alarm and other functions;
The rewinding adopts A air shaft structure, which is convenient for loading and unloading;
The unwinding adopts the photoelectric automatic correction system to make irregular materials can be slit normally
Automatic discharge device for flat knife slitting waste edge
Pneumatic shaft feeding, 3 inches

Applications

This machine is suitable for slitting various roll materials such as BOPP, PET, CPP, CPE, PVC, etc. During the production process, the materials are slit and rewinded according to different need.

PLF-1200N Full-Auto Photoelectric Paper Trimming Machine for Filter Production Equipment

Machine characteristics

PLF-1200N Full-Auto Photoelectric Paper Trimming Machine for Filter Production Equipment

Operating procedures

PLF-1200N Full-Auto Photoelectric Paper Trimming Machine for Filter Production Equipment

Machine packing

PLF-1200N Full-Auto Photoelectric Paper Trimming Machine for Filter Production Equipment

PLF-1200N Full-Auto Photoelectric Paper Trimming Machine for Filter Production Equipment Images
